2019 Model Used Crawler Cranes 350 Ton Crawler Crane SANY SCC3500A With Superlift

Product Description

2019 model Used Crawler Cranes SANY SCC3500A

Production Details:

2019 model Used Crawler Cranes SANY SCC3500A boom 78m, luffing jib 60m, have superlift

Product Performance Advantages:

The SANY SCC3500A crawler crane is a high-performance heavy-lifting machine with the following significant advantages:

1.Superior Lifting Capacity

• The maximum rated lifting capacity is 350 tons,with a maximum lifting moment of 2,400 ton-meters.

• The main boom length ranges from 24 meters to 84 meters.With a 60-meter+60-meter luffing jib,it can meet a variety of complex working conditions.

2.Efficient Power and Hydraulic Systems

• Equipped with a Weichai WP10HG336E470 diesel engine,offering a rated power of 247 kW and a maximum torque of 1,600 N·m.It meets China's Stage IV emission standards for non-road mobile machinery.

• The hydraulic system features electro-proportional control,with an open-type variable displacement piston pump for efficient power output and precise control.

3.Advanced Control System

• The crane is equipped with SANY's second-generation integrated control system(SYIC-2),which offers high integration and strong compatibility.It ensures precise and reliable operation.

• Intelligent technology integrates four major functions:"smart interaction,smart assistance,smart safety,and intelligent operation."It supports intelligent operations such as one-key outrigger deployment,one-key rope threading,and boom area limitation.

4.Excellent Stability and Safety

• The crane features a wide-track crawler design with a ground pressure as low as 0.14 MPa,ensuring stability on complex terrains.

• It is equipped with various safety devices,such as anti-rear-tilt devices,rope disorder recognition for the winch,and three-color load warning lights,which monitor the equipment's status in real-time.

5.Efficient Assembly and Transportation

• The entire machine is designed in a modular fashion,with transport dimensions of 12,000 mm×3,000 mm×3,100 mm.The maximum single-piece transport weight is 53 tons.

• It supports quick assembly and disassembly,and no over-height transportation is required,reducing transportation costs.

6.Ergonomic Design

• The new cab design features heating and air conditioning,an air-suspension seat,and a 12.8-inch triple-smart screen,providing a comfortable operating environment.

• The control levers have flexible function settings that can be customized to meet different operating preferences.

7.Wide Applicability

• Suitable for bridge construction,wind power lifting,petrochemicals,and other fields,capable of handling a variety of complex working conditions.

• It is equipped with a reserved interface for future upgrades and extensions.

The SANY SCC3500A crawler crane,with its superior lifting capacity,efficient power system,advanced control technology,and excellent stability and safety,is an ideal choice for large-scale lifting tasks.

Pictures show:
